HMP/3000-Piston Filling Machine

HMP/3000-Piston Filling Machine

HMP 3000 Volumetric filling Machine’s Electro Pneumaticly controlled ,volumetric filling system, Electronically , product level controlled Filling Tank(hopper) mounted over the machine All adjustments can be done through PLC All the surfaces to which product touches are made of SS 316, Filling ranges from 5-50 ml ,10-000 ml,100-1000 ml,500-5000 ml ,other filling ranges are also designable as per requirement , The sealings,o rings ,etc..are designed with referance to the product’s chemical specifications , The machine is suitable for viscous products ,and semi viscous products


  • Capacity is 1000-6000 pieces/hour
  • Filling Range is 100cc-1000cc-5000cc
  • Made of AISI 304 Stainless Steel
  • Working method is electro-pneumatic
  • Number of nozzles are 2-10
  • 380 V working tension (220 V optional)
  • PLC and HMI Control
  • Sensitivity ± %0,3
  • Working Pressure is 6-8 bar
  • Filling Type is volumetric


  • Vegetable Oils
  • Juices
  • Marmelade/Cream/Honey
  • Paint/Solvent
  • Chemical Oils
  • Shampoo/Detergent
  • Liquid Soap
  • Cleaning Agents
  • Lotion/Solution
  • Medical Products
  • Liquid Fertilizers
