Vacuum Filling Machine-HMV/3000

Vacuum Filling Machine-HMV/3000


HMV 3000 Vacuum filling (free flow principle) The machine works with free flow &vacuuming system, Suitable for Liquids ,Agressive liquids and foaming liquids like glass cleaner or vinegaar , All bottles are filled at the same level irresspective of the inner capacities of the bottles ,Vaccum system prevents foaming , Simple design ,easy to change from bottles to bottles ,


TECHNICAL DETAILS

  • Capacity is 2000-4000 pieces/hour
  • Filling Range is 500cc-5000cc
  • Internal Vacuum Tank
  • Made of AISI 304 Stainless Steel
  • Number of nozzles are 6 — 12
  • 380 VAC working tension (220 VAC optional)
  • Sensitivity is %± 0,4 for glassbottle
  • Designed for foamy products
  • Level Control Filling
  • Working Pressure is 6-8 bar



PRODUCTS TO BE FILLED

  • Juicy Drinks
  • Foamy cleansers and chemicals
  • Cleaning Agents
  • Lotion/Solution
  • Medical Liquid Products
  • Liquid Fertilizers
  • Other non-carbonated aqueous beverages
